MultiOne 9 Series – Miniloader
STANDARD FEATURES Model: 9.5 Best lift capacity-weight ratio Power: 50 hp Speed: 25 km/h Tipping load: 2600 kg – 5732 lbs Flow rate: 85…
Description
MultiOne 9 series is the best articulated mini loader on the market in term of best lift capacity-weight ratio.
The 9 series is the evolution of the top class GT series: the new series continues to impress with a brand new architecture and design making it the only compact mini loader in its class to achieve the performance and standards in a very competitive and cost effective packagage.
The 9 Series offers superb value for money to the customer looking for all the benefits of a compact yet powerful package. MultiOne mini loaders come at a competitive price without sacrificing power and quality.
These machines are perfectly suited for more demanding jobs requiring high lifting power and pushing force.
9 Series Plus:
Advanced and modern frame design
Best lift capacity-weight ratio
Tier 4 Final
ADDITIONAL DETAILS
Standard Features
Model 9.5
Best lift capacity-weight ratio
Power: 50 hp
Speed: 25 km/h
Tipping load: 2600 kg – 5732 lbs
Flow rate: 85 l/min
Pushing Force (c): 1950 kgf
Weight: 2100kg
Lift height: 3,21 m – 126.4 in
Best lift capacity-weight ratio
Power: 50 hp
Speed: 25 km/h
Tipping load: 2600 kg – 5732 lbs
Flow rate: 85 l/min
Pushing Force (c): 1950 kgf
Weight: 2100kg
Lift height: 3,21 m – 126.4 in
Technical Data
| Engine | Yanmar 4TNV88 |
| Power (Iso Gross) | 50 HP / 37 kW |
| Fuel | Diesel |
| Transmission | Hydrostatic |
| Drive speed (max) | 25 km/h (15.5 mph) |
| Aux. hydraulic oil flow | 85 l/min (22.5 gal/min) |
| Max lifting height | 3,21 m (126.4 in) |
| Breakout force / 50 cm | 2200 kg (4850 lbs) |
| Turning radius: inside/outside | 1030 / 2550 mm (40.5 / 100.4 in) |
| Standard tires (Tractor profile) | 31×15.50-15 (400/50-15) |
| Weight | 2100 kg (4630 lbs) |
| Tipping load (w/backweights) | 2600 kg (5732 lbs) |
| Lifting capacity (straight and w/backweights) | 2080 kg (4585 lbs) |
| Lifting capacity (fully articulated and w/backweights) | 1600 kg (3527 lbs) |
| Code | C965000 |
